Techical Parameter:
<
TYPES OF MACHINE | SH120 | ||
Injection Station Part | Unit | A | B |
Screw diameter | mm | 45 | 50 |
Injection pressure | Mpa | 174 | 141 |
Screw L/D ratio | ---- | 21:1 | 19:1 |
Screw stroke | mm | 172 | |
plasticizing capacity | cm3/S | 32 | |
injection rate | g/S | 106 | |
injection volume | cm3 | 274 | 338 |
Theoretic Injection weight(PS) | g | 258 | 319 |
OZ | 9.1 | 11.2 | |
Injection Station Impetus | KN | 54 | |
Screw speed | r.p.m | 180 | |
Shot stroke | mm | 260 | |
Clamping Unit | Unit | ||
Clamping force | KN | 1200 | |
Clamping stroke | mm | 350 | |
Mould Thickness | mm | 175-450 | |
Space between tie bars | mm | 410×360 | |
Ejector force | KN | 34 | |
Ejector stroke | mm | 80 | |
Ejecter Pin Number | ---- | 1 | |
Others | Unit | ||
Hydraulic system power | Mpa | 14 | |
Temp. control zones | ---- | 3+1 | |
Pump Servo motor power | KW | 11 | |
Heating power | KW | 10 | |
Overall Electric Power | KW | 22 | |
Net Weight | t | 4 | |
Sizes(L×W×H) | m | 4.25×0.95×1.8 | |
Oil Box Capacity | L | 240 |
